| 9 heads linear polishing machine | ||||||||
| Machine size(mm) | 6000×2200×2300 | Use pressure to control the lifting of the polisher, the pressure can be adjust. Swinging beam drives the polisher to move, the moving speed can be adjust. Belt type feeding plate working table,belt running speed can be adjusted; The electrical system use PLC and man-machine interface. Replacement cycle of consumables: Diamond: half a month-1 month, Grinding Block: half a-1 day. Different hardness degrees of tile, output difference can reach more than 20%. | ||||||
| Overroll frame size(mm) | 1500×1200×700 | |||||||
| Power(kW) | 79.2 | |||||||
| Weight(T) | 8 | |||||||
| Grind head | 9 | |||||||
| Grind diamater(mm) | φ280 | |||||||
| Working width(mm) | 300-1000 | |||||||
| Working thickness(mm) | 10-60 | |||||||
| Caterpillar belt speed(m/min） | 0.5-1.2 | |||||||
| Capacity(8 hours) | 250-400㎡ | |||||||
| Water consumption | 1.3T/head/hour | |||||||
| 12 heads linear polishing machine | ||||||||
| Machine size(mm) | 7200×2800×2100 | Use pressure to control the lifting of the polisher, the pressure can be adjust. Swinging beam drives the polisher to move, the moving speed can be adjust. Belt type feeding plate working table,belt running speed can be adjusted; The electrical system use PLC and man-machine interface. Replacement cycle of consumables: Diamond: half a month-1 month, Grinding Block: half a-1 day. Different hardness degrees of tile, output difference can reach more than 20%. | ||||||
| Overroll frame size(mm) | 1870×1010×700 | |||||||
| Power(kW) | 101.2 | |||||||
| Weight(T) | 10 | |||||||
| Grind head | 12 | |||||||
| Grind diamater(mm) | φ280 | |||||||
| Working width(mm) | 300-1000 | |||||||
| Working thickness(mm) | 10-60 | |||||||
| Caterpillar belt speed(m/min) | 0.5-1.2 | |||||||
| Capacity(8 hours) | 340-500㎡ | |||||||
| Water consumption | 1.3T/head/hour | |||||||
| 16 heads linear polishing machine | ||||||||
| Machine size(mm) | 8800×2800×2100 | Use pressure to control the lifting of the polisher, the pressure can be adjust. Swinging beam drives the polisher to move, the moving speed can be adjust. Belt type feeding plate working table,belt running speed can be adjusted; The electrical system use PLC and man-machine interface. Replacement cycle of consumables: Diamond: half a month-1 month, Grinding Block: half a-1 day. Different hardness degrees of tile, output difference can reach more than 20%. | ||||||
| Overroll frame size(mm) | 1870×1010×700 | |||||||
| Power(kW) | 138.2 | |||||||
| Weight(T) | 13 | |||||||
| Grind head | 16 | |||||||
| Grind diamater(mm) | φ280 | |||||||
| Working width(mm) | 300-1000 | |||||||
| Working thickness(mm) | 10-60 | |||||||
| Caterpillar belt speed(m/min) | 0.5-1.2 | |||||||
| Capacity(8 hours) | 340-500㎡ | |||||||
| Water consumption | 1.3T/head/hour | |||||||
| 9 heads linear polishing machine | ||||||||
| Machine size(mm) | 6000×2200×2300 | Use pressure to control the lifting of the polisher, the pressure can be adjust. Swinging beam drives the polisher to move, the moving speed can be adjust. Belt type feeding plate working table,belt running speed can be adjusted; The electrical system use PLC and man-machine interface. Replacement cycle of consumables: Diamond: half a month-1 month, Grinding Block: half a-1 day. Different hardness degrees of tile, output difference can reach more than 20%. | ||||||
| Overroll frame size(mm) | 1500×1200×700 | |||||||
| Power(kW) | 79.2 | |||||||
| Weight(T) | 8 | |||||||
| Grind head | 9 | |||||||
| Grind diamater(mm) | φ280 | |||||||
| Working width(mm) | 300-1000 | |||||||
| Working thickness(mm) | 10-60 | |||||||
| Caterpillar belt speed(m/min） | 0.5-1.2 | |||||||
| Capacity(8 hours) | 250-400㎡ | |||||||
| Water consumption | 1.3T/head/hour | |||||||
| 12 heads linear polishing machine | ||||||||
| Machine size(mm) | 7200×2800×2100 | Use pressure to control the lifting of the polisher, the pressure can be adjust. Swinging beam drives the polisher to move, the moving speed can be adjust. Belt type feeding plate working table,belt running speed can be adjusted; The electrical system use PLC and man-machine interface. Replacement cycle of consumables: Diamond: half a month-1 month, Grinding Block: half a-1 day. Different hardness degrees of tile, output difference can reach more than 20%. | ||||||
| Overroll frame size(mm) | 1870×1010×700 | |||||||
| Power(kW) | 101.2 | |||||||
| Weight(T) | 10 | |||||||
| Grind head | 12 | |||||||
| Grind diamater(mm) | φ280 | |||||||
| Working width(mm) | 300-1000 | |||||||
| Working thickness(mm) | 10-60 | |||||||
| Caterpillar belt speed(m/min) | 0.5-1.2 | |||||||
| Capacity(8 hours) | 340-500㎡ | |||||||
| Water consumption | 1.3T/head/hour | |||||||
| 16 heads linear polishing machine | ||||||||
| Machine size(mm) | 8800×2800×2100 | Use pressure to control the lifting of the polisher, the pressure can be adjust. Swinging beam drives the polisher to move, the moving speed can be adjust. Belt type feeding plate working table,belt running speed can be adjusted; The electrical system use PLC and man-machine interface. Replacement cycle of consumables: Diamond: half a month-1 month, Grinding Block: half a-1 day. Different hardness degrees of tile, output difference can reach more than 20%. | ||||||
| Overroll frame size(mm) | 1870×1010×700 | |||||||
| Power(kW) | 138.2 | |||||||
| Weight(T) | 13 | |||||||
| Grind head | 16 | |||||||
| Grind diamater(mm) | φ280 | |||||||
| Working width(mm) | 300-1000 | |||||||
| Working thickness(mm) | 10-60 | |||||||
| Caterpillar belt speed(m/min) | 0.5-1.2 | |||||||
| Capacity(8 hours) | 340-500㎡ | |||||||
| Water consumption | 1.3T/head/hour | |||||||
